Flue Gas Desulfurization (FGD) Processes. In many plants it is necessary to remove sulfur from the flue gases flue gases Flue gas (sometimes called exhaust gas or stack gas) is the gas that emanates from combustion plants and which contains the reaction products of fuel and combustion air and residual substances such as particulate matter (dust), sulfur oxides, nitrogen oxides, and carbon monoxide (Table 3.7). › topics › flue-gas

Flue Gas - an overview | ScienceDirect Topics

What is flue gas desulfurization process?

In a flue gas desulphurisation system (FGD), sulphur compounds are removed from the exhaust emissions of fossil-fuelled power stations. This is done by means of an industrial process through the addition of absorbents. ... In this method, the flue gases are steam-saturated with the absorbent in aqueous solution.

Where is flue gas desulfurization used?

Flue Gas Desulfurization Systems: Scrubbers

They are used in coal-and-oil fired combustion units including utility and industrial boilers, municipal and medical waste incinerators, petroleum refineries, cement and lime kilns, metal smelters, and sulphuric acid plants.

How effective is flue gas desulfurization?

For a typical coal-fired power plant, FGD systems will remove ~95% of the SO₂ in the flue gases. FGD predominantly employs two methods of filtering the emissions (dry or wet scrubbing) for coal-burning plants to be in compliance with regulations mandated by the EPA's Effluent Limitation Guidelines (ELG).

What is used for flue gas desulfurization?

Lime plays a key role in many air pollution control applications. Lime is used to remove acidic gases, particularly sulfur dioxide (SO₂) and hydrogen chloride (HCl), from flue gases.

How Flue Gas Desulfurization (FGD) Works

What is Flue Gas Desulfurization Upsc?

Removal of Sulfur Dioxide is called as Flue-gas Desulphurization (FGD). It seeks to remove gaseous pollutants viz. SO₂ from exhaust flue gases generated in furnaces, boilers, and other industrial processes due to thermal processing, treatment, and combustion.

Why is it necessary to remove sulfur dioxide from power stations?

Unfortunately, power plants also produce large amounts of nitrogen oxides and sulfur dioxide—the pollutants that cause acid rain—when they burn fossil fuels, especially coal, to produce energy. ... It also reduces the amount of nitrogen oxides that power plants can release.

How does SO2 scrubbing work?

How does a scrubber work? Once sulfur is burned and produces SO₂, the exhaust gas passes through the scrubber where a spray mixture of limestone (or other chemical reagent) and water reacts with the SO₂. The reaction enables the SO₂ to be removed before it's released into the atmosphere.

What is the disadvantage of wet limestone scrubbing?

Other drawbacks of wet-limestone scrubbing are large up-front capital costs, large equipment size and substantial predictive and corrective maintenance requirements. Substituting hydrated lime as the reagent reduces equipment size and costs, but increases reagent costs and material handling issues.

How much does flue gas desulfurization cost?

Total capital costs vary from $60 to $100/kw and $94 to $145/kw, respectively, for the limestone and sodium solution scrubbing systems for this model plant. Higher capital costs are often required for application of FGD systems to existing plants than for application to sim- ilar new plants.

What is flue gas treatment?

Flue gas treatment, a process designed to reduce the amount of pollutants emitted from the burning of fossil fuels at an industrial facility, a power plant, or another source. ... If left untreated, flue gas from power plants, industrial facilities, and other sources can substantially affect local and regional air quality.

How does limestone remove sulfur dioxide?

Limestone is a naturally occurring calcium carbonate rock which can react with sulfur dioxide. ... A much higher efficiency of SO2 removal can be realized when the flue gas, after it has passed the precipitators, is scrubbed with an aqueous slurry of pulverized limestone.

How is SO2 removed from power stations?

By reducing electricity use, everyone can reduce the emission of air pollutants from power stations. Sulfur dioxide may be removed from the waste gases by a process called gas scrubbing.

What is desulfurization of fuel?

Desulfurization is the removal of sulfur or sulfur compounds (as from coal or flue gas), mostly from fuels. The most commonly required desulfurization process is in natural gas, but it is also required for flue gas, coal and oil.

What is limestone scrubbing?

A system for removal of SO₂ from pollution sources by injecting calcined limestone into the exhaust gas system. Most of the SO₂ in the gas is absorbed by the droplets of absorbent, and is oxidized into calcium sulfate and calcium sulfite compounds. ...

What is flue gas in boiler?

Flue gas (sometimes called exhaust gas or stack gas) is the gas that emanates from combustion plants and which contains the reaction products of fuel and combustion air and residual substances such as particulate matter (dust), sulfur oxides, nitrogen oxides, and carbon monoxide (Table 3.7).

What is wet flue gas?

Wet flue gas cleaning, in turn, is an efficient way to bring the flue gases down to near zero emission levels in SO₂, HCl and NH₃. A customized flue gas scrubber solution enables you to capture particulate emissions and/or maximize the efficiency of your SNCR or SCR system by removing NH₃ slip from flue gas.

Do scrubbers reduce SO2?

Electricity generating units may use sulfur dioxide (SO2) scrubbers to meet the requirements of Phase II of the Acid Rain S02 Reduction Program. Additionally, the use of scrubbers can result in reduction of mercury emissions. ... Advanced, state-of-the-art wet scrubbers can provide SO2 removal in excess of 95 percent.

Do scrubbers remove SO2?

Commonly known as scrubbers, flue gas desulfurization (FGD) systems are a highly efficient and reliable means of removing SO2 as well as particulate matter, hydrochloric acid and other air toxics.

What are different methods used to control SO2 in the flue gases explain any two?

Using lime to capture the SO2 reduces operating costs as compared to using either caustic or soda ash. There are four types of dry/semi-dry FGD - spray dryer absorber (SDA), sorbent injection, and dry circulating FGD. ... In this process atomized lime slurry is sprayed into the flue gas within the reaction vessel.

What effect is caused by sulfur dioxide environment?

Environmental effects

When sulfur dioxide combines with water and air, it forms sulfuric acid, which is the main component of acid rain. Acid rain can: cause deforestation. acidify waterways to the detriment of aquatic life.

How flue gases can be controlled and filtered in a power plant?

At power plants, flue gas is often treated with a series of chemical processes and scrubbers, which remove pollutants. Electrostatic precipitators or fabric filters remove particulate matter and flue-gas desulfurization captures the sulfur dioxide produced by burning fossil fuels, particularly coal.

How can Sulphur dioxide be controlled by pollution?

The two major emissions control methods are sorbent injection and flue gas desulfurization: Sorbent injection involves adding an alkali com- pound to the coal combustion gases for reac- tion with the sulfur dioxide. Typical calcium sorbents include lime and variants of lime. Sodium-based compounds are also used.

Does Eskom use FGD?

The specific FGD technology selected by Eskom is water-intensive and, in the dry hinterlands of Limpopo, it will have to be piped in. This is over and above the significant amount of water that must be sourced for Medupi to operate.

How do scrubbers reduce air pollution?

Scrubbers are air pollution control devices that use liquid to remove particulate matter or gases from an industrial exhaust or flue gas stream. This atomized liquid (typically water) entrains particles and pollutant gases in order to effectively wash them out of the gas flow.
